Atomic Absorption Spectrophotometer - Single Beam

Atomic Absorption Spectrophotometer Ebert type monochromator with 1800 lines/ mm halo graphic grating, 0 to2nm SBW, 190-900nm Wavelength range.

8 hollow cathode Lamp turret assembly with modulated four independent power supplies.

Built in background corrector in the system using high intensity and high speed Deuterium lamp.

Automatic calibration using up to maximum 10 standards and recalibration with a single standard.

Direct concentration readout using different modes (K- Factor Linear regression and Quadratic regression).

Display of the signal energy in the form of BAR signal and numeric form. ABS. % TRANS and CONC display facility.

Absorbance range from 0 to 3.0 ABS. Titanium Burner of 100 mm Air-acetylene and 50 mm N 20 – Acetylene Flames.

Corrosion resistant nebulizer with Platinum – iridium capillary, Impact bead.

Supplied with computer interface software, cylinder, regulator, 3 standard lamps & compressor.
